Features:
-
Built-in vehicle support stand feature allows complete open access under the vehicle
-
Lift entire vehicle with patented controls and shop air
-
Perfect for shops with low ceiling heights
-
Small wheel adapters
-
Dual trigger control valve allows synchronized raising and lowering of vehicle
-
Sold in pairs
-
US Patent #D357,106 & 5,484,134
-
Easily handles wheel sizes 19.5" to 24.5"
-
Optional small wheel adapters available to accommodate 16" to 19.5"
Specifications:
-
Capacity Per Set 40,000 lb (18,143 kg)
-
Minimum Start Height Floor Level
-
Maximum Lift Height 30 in (76 cm)
-
Power Shop Air
-
Required Air Pressure 160 psi (11 bar)
-
Stroke 30 in (76 cm)
-
Minimum Wheel Diameter (w/ Adapters) 14 in (36 cm)
-
Minimum Wheel Diameter (w/o Adapters) 21 in (53 cm)
-
Maximum Wheel Diameter 24.5 in (62 cm)
-
Dimensions (H x W x D) 63 in x 45 in x 44 in (160 cm x 114 cm x 112 cm)
-
Shipping Weight 1,965 lb (891 kg)
| Weight (w/o wheels) | 20 LBS |
|---|---|
| Weight Capacity | 60 LBS |
| Folded (w/o wheels) | 32.5"L x 18.5"W x 16.5"H |
| Folded (w/ wheels) | 32.5"L x 24"W x 18.5"H |
| Door Pass Through | 24 |
| Frame | Aluminum |
| Stand Up | 35"L x 24"W x 37-45"H(front to back wheel) |
| Size | S, XL, XS |
| Color | Gray 2, Green 2, Orange 1, Orange 2, Violet |
